ETAS ES800 System | User Guide
13.4 Joining and Separating Modules (Stacking)
13.4.1 Operating State During Stacking
13.4.2 Video: Joining and Separating Modules
The video shows how to join and separate the modules of the ES800 system.
13.4.3 Connecting an ES800 Base Module to an ES800 Module
Required Tools
You will need a screwdriver or a coin to fasten the ES800 Base Module to an ES800
module.
Preparations
Watch the video on stacking the modules
1. Watch the video on the ETAS website ES800 module stack.to see the steps
involved in stacking the modules.
Disconnecting the Base Module from the voltage supply
2. Disconnect the Base Module from the voltage supply.
Removing the protective cap from the system connector
3. Turn the ES800 module over and place it on its top side.
NOTE
Possible damage or destruction of electronics!
Only connect the Base Module to the modules of the system in the de-energized
state. Only stack the modules in the de-energized state.
NOTE
Read the following chapter carefully for detailed descriptions of how to join and
separate the modules.
NOTE
The video can be found on the ETAS website ES800 module stack.
NOTE
Possible damage or destruction of electronics!
Only connect the Base Module to the modules of the system in the de-energized
state. Only stack the modules in the de-energized state.
