53 | ES830.1 Rapid Prototyping Module
ETAS ES800 System | User Guide
6.5.4 Simulation Controller
The rapid prototyping model is executed on the simulation controller of the
ES830.1 module.
Solid State Drive (Internal)
The operating system and the rapid prototyping model are stored on the internal
solid state drive (SSD).
Board Controller
The board controller controls and monitors the Wake-Up function of the module,
the control and display elements as well as the digital inputs and outputs.
6.5.5 "Power" Key
If the "Power" key is actuated, the Rapid Prototyping Module ES830.1 switches to a
different operating state ("On", "Standby" or "Off", see chapter
6.6 on page 55).
Remote Function of the "Power" Key
If necessary, the function of the "Power" key on the ES830.1 module can be
assumed by an external "Remote Power" key. To use this function, connect an
external key to the "IN_POWER_BUTTON" pin at the "I/O" connection (see chapter
16.10.11 on page 176).
6.5.6 "User" Key
Pressing the "User" key enables you to start or interrupt the configuration in INTE-
CRIO, e.g., a switch between different functions in the model.
6.5.7 Acoustic Signal Generator
Internal Acoustic Signal Generator
The ES830.1 features an acoustic signal generator.
External Acoustic Signal Generator
The status of the internal acoustic signal generator is also output as an electrical
signal at a pin of the "I/O" connection. An external signal generator (Piezo buzzer)
can also be directly connected here and housed in the passenger cell.
NOTE
The "Power" key or an external "Remote Power" key must not be actuated while
the firmware or configuration software of the ES830.1 Rapid Prototyping Module
is being updated or during installation.
