134 | Applications
ETAS ES800 System | User Guide
10 Vehicle bus connections: CAN K106, K107,
CBAC150,
CBAC160,
CBCX130,
CBCX131.1
Vehicle bus connections: CAN/LIN/FlexRay CBCFI100
Vehicle bus connections: FlexRay CBFX131
11 Fast Ethernet connection to ES4xx, ES63x and ES930
modules
CBE400.2,
CBE401.1
Fast Ethernet connection and power supply to the ES4xx,
ES63x and ES9x modules
CBEP420,
CBEP425
12 Fast Ethernet connection to ES520, ES59x, ES600, ES610,
ES620 and ES650 modules
CBE130,
CBE140
NOTE
Only one ES830.1 Rapid Prototyping Module can be operated in an ES800 module
stack.
NOTE
The ES830.1 Rapid Prototyping Module must always be operated beneath inter-
face modules (e.g. ES89x) in the module stack. Information on positioning the
module types in the module stack can be found in chapter
13.3 on page 114.
WARNING
Risk due to undefined vehicle behavior during an ECU reset
If you operate the product in combination with ETKs, the ECU must not be reset
in an uncontrolled manner.
- Only make changes when the vehicle is stationary (e.g., changes to the test
setup, changes to the ETK configuration, software updates).
- If you are using the Drive Recorder ES820.1, wait until its MEAS LED is lit con-
tinuously before driving.
Cables
in
Fig. 14-1
Function Short
name
