201 |
ETAS ES800 System | User Guide
Assignment of the Automotive Ethernet Signal to the open Wires
The assignment of the open wires of a cable section to the signals of an Automo-
tive Ethernet channel [N] is represented in the table.
Temperature Range
-40 °C to +85 °C/ -40 °F to +185 °F
Order Information
Color Signal Meaning
Green AE [n]+ Automotive Ethernet, channel [n], BI_DA+
White AE [n]- Automotive Ethernet, channel [n], BI_DA-
Order name Short name Order
number
Automotive Ethernet Splitter Cable 100 Mbit/s,
Yamaichi YCP - 4x Open Wire (8mc - 4x 2c),
0m4
CBEB245.1-0m4 F 00K 111 431
Automotive Ethernet Splitter Cable 100 Mbit/s,
Yamaichi YCP - 4x Open Wire (8mc - 4x 2c), 2m
CBEB245.1-2 F 00K 111 385
