ETAS ES800 System | User Guide
Pin Assignments of the Cable at the FLX1/FLX2 Interface
The signals of the FLX1FLX2 interface of the ES891.x are assigned to the DSUB
socket-plug combinations of the cable CBCFI100 as follows:
Lemo
[side A]
DSUB,
color: gray
[side B = side C]
Pin Signal Pin Signal
1 -
Cable CBCFI100
1 -
2 FLX1_LOW 2 FLX1_LOW
3 FLX1_GND 3 FLX1_GND
4 FLX2_HIGH 4 -
5 FLX2_GND 5 -
6 FLX1_GND 6 FLX1_GND
7 FLX1_HIGH 7 FLX1_HIGH
8 FLX2_LOW 8 -
9 -
DSUB,
color: black
[side D = side E]
Pin Signal
1 -
2 FLX2_LOW
3 FLX2_GND
4 -
5 -
6 -
7 FLX2_HIGH
8 -
9 -
NOTE
The cable CBCFI100 can be used at the interfaces CAN/CAN and CAN/LIN of the
ES88x/ ES89x and at the interface FLX1/FLX2 of the ES891.x.
Order name Short name Order
number
CAN, FlexRay and LIN Interface Y-Cable, Lemo
1B FGC - 2xDSUB (8mc-9fc + 9mc), 2
m
CBCFI100.1-2 F 00K 106 893
