ETAS ES800 System | User Guide
Pin Assignments of the Cable at the CAN3/LIN Interface
The signals of the CAN3/LIN interface are assigned to the DSUB socket-plug com-
binations of the cable CBCFI100 as follows:
Lemo
[side A]
DSUB,
color: gray
[side B, side C]
Pin Signal Pin Signal
1 LIN_UBATT 1 -
2 CAN3_LOW 2 CAN3_LOW
3 CAN3_GND 3 CAN3_GND
4 LIN 4 -
5 LIN_GND 5 -
6 CAN3_GND 6 CAN3_GND
7 CAN3_HIGH 7 CAN3_HIGH
8 CAN3_UBAT
T
8 -
9 -
DSUB,
color: black
[side D, side E]
Pin Signal
1 -
2 -
3 LIN_GND
4 -
5 -
6 -
7 LIN
8 -
9 LIN_UBATT
