216 |
ETAS ES800 System | User Guide
Pin Assignments of the Cable at the CAN5/LIN Interface
The signals of the CAN5/LIN interface are assigned to the DSUB socket-plug com-
binations of the cable CBCFI100 as follows:
Lemo
[side A]
DSUB,
color: gray
[side B, side C]
Pin Signal Pin Signal
1 LIN_UBATT 1 -
2 CAN5_LOW 2 CAN5_LOW
3 CAN5_GND 3 CAN5_GND
4 LIN 4 -
5 LIN_GND 5 -
6 CAN5_GND 6 CAN5_GND
7 CAN5_HIGH 7 CAN5_HIGH
8 CAN5_UBAT
T
8 -
9 -
DSUB,
color: black
[side D, side E]
Pin Signal
1 -
2 -
3 LIN_GND
4 -
5 -
6 -
7 LIN
8 -
9 LIN_UBATT
NOTE
The cable CBCFI100 can be used at the interfaces CAN/CAN and CAN/LIN of the
ES88x/ ES89x and at the interface FLX1/FLX2 of the ES891.x.
Order name Short name Order
number
CAN, FlexRay and LIN Interface Y-Cable, Lemo
1B FGC - 2xDSUB (8mc-9fc + 9mc), 2 m
CBCFI100.1-2 F 00K 106 893
