42 | ES820.1 Drive Recorder
ETAS ES800 System | User Guide
General Events
"Wake-Up" Events (change from "Low power standby" to "Fast boot
standby")
"Wake-Up" Events (change from "Low power standby" to "Active
on")
"Wake-Up" Events (change from "Passive on" to "Active on")
Event Abbrevia
-
tion
Description
No. in
Fig. 5-5
1 PWR On Power supply on
11 PWR Off Power supply off
Event Abbrevia-
tion
Description
No. in
Fig. 5-5
12 Fast boot preparation upon entry into the time frame
Event Abbrevia-
tion
Description
No. in
Fig. 5-5
2 PBP Pressing the "Power" button on the module
3 On pin Pressing the external remote "Power" button or trigger
event at the digital input ("PSCI" pin, "I/O" connection),
Low to High
4 On time Start at a specific point in time (configurable timer)
Event Abbrevia-
tion
Description
No. in
Fig. 5-5
2 PBP Pressing the "Power" button on the module
3 On pin Pressing the external remote "Power" button or trigger
event at the digital input ("PSCI" pin, "I/O" connection),
Low to High
4 On time Start at a specific point in time (configurable timer)
