·114·
Operating manual
CNC 8055
CNC 8055i
6.
MANUAL
·T· MODEL
SOFT: V02.2X
Jog
6.1 Jog
6.1.1 Continuous Jog
Once the % override of the jogging feedrate (indicated by axis-machine parameter "JOGFEED") has
been selected with the switch at the Operator Panel , press the jog keys corresponding to the desired
axis and to the desired jogging direction.
The axes can be jogged one at a time and in different ways depending on the status of the general
logic input "LATCHM":
• If the PLC sets this mark low, the axes will be jogged while pressing the corresponding
Jog key.
• If the PLC sets this mark high, the axes will move from the moment the corresponding
JOG key is pressed until the [STOP] key or other JOG key is pressed. In this case,
the movement will be transferred to that indicated by the new key.
If while jogging an axis, the rapid key is pressed, the axis will move at the feedrate
established by machine parameter "G00FEED" for this axis as long as this key stays
pressed. This feedrate will be applied while this key is pressed and it will restore the
jogging feedrate percentage (0% to 120%) indicated in axis machine parameter
"JOGFEED" when this key is released.
