·168·
Operating manual
CNC 8055
CNC 8055i
10.
PLC
·T· MODEL
SOFT: V02.2X
Edit
10.1 Edit
Once this option is selected, indicate with the corresponding softkey the PLC program to be edited.
• The PLC program (PLC_PRG)
• The PLC error file (PLC_ERR)
• The PLC message file (PLC_MSG)
The cursor can be moved line by line with the [] [] arrow keys or page by page with the "page
up" and "page down" keys.
The cursor position or line number will be displayed in a white window inside the communications
window next to the CAP/INS indicator window.
This operating mode offers various options that are described next.
Once any of those options has been selected, the user can move the cursor over this line by means
of the [] [] keys. Also, with the [] key, the cursor may be placed over the first character of the
editing window and, with the [] key over the last character.
"EDIT" softkey
With this option it is possible to edit new lines or blocks of the selected program. Before pressing
this softkey, the block after which the new ones will be added must be selected with the cursor.
Once this option has been selected, the softkeys will change colors and they will appear over white
background showing the information corresponding to the type of editing possible at that point.
Pressing the [ESC] key deletes the block being edited. From this point on, the block may be edited
again.
Once the block has been edited, press [ENTER]. This new block will be added to the program after
the one indicated by the cursor.
The cursor will position over the new edited block and the editing area (window) will be cleared so
another block can be written.
The editing area must be empty in order to quit this option. If it's not, press [ESC] to delete that
information and then press [ESC] again.
"MODIFY" softkey
This option permits modifying the contents of a selected program block. Before pressing this softkey,
select with the cursor the block to be modified .
Once this option is selected, the softkeys will change their color showing their type of modifying
option over a white background.
By pressing the [ESC] key, the information corresponding to that block and which was shown in the
editing area will be cleared. From this point on, the block may be edited again.
To quit the block modifying mode, press [CL] or [ESC] to clear the editing window and then press
[ESC] again. This way, the selected block will not be modified.
Once the block contents have been modified, press [ENTER]. The new block will replace the
previous one.
"FIND" softkey
This option is used to find a specific text within the selected program. When selecting this option,
the softkeys will show the following options:
BEGINNING
This softkey positions the cursor over the first program block which is then selected quitting the "find"
option.
