Operating manual
CNC 8055
CNC 8055i
DIAGNOSIS
13.
·T· MODEL
SOFT: V02.2X
·239·
Interesting notes
13.7 Interesting notes
The CNC carries out a series of sequential tests. If the result obtained is not correct, it may stop
axes feed and spindle rotation (by canceling their analog voltages and Enables), as well as stopping
the execution of the PLC program or activating the external emergency output (01).
Type of test When doing Stop axes and
spindles
Stop the PLC Activates the
emergency
output
Temperature Always Yes No Yes
Battery out Always No No No
Flash memory From Diagnosis Yes Yes Yes
RAM memory From Diagnosis Yes No Yes
External emergency EXEC/SIMUL Yes No No
Board voltage EXEC/SIMUL Yes No Yes
PLC in execution EXEC/SIMUL Yes --- Yes
PLC User errors EXEC/SIMUL Yes No No
PLC watchdog PLC in execution Yes Yes Yes
