·224·
Operating manual
CNC 8055
CNC 8055i
13.
DIAGNOSIS
·T· MODEL
SOFT: V02.2X
Tests
13.3 Tests
Memory test
This option checks the status of the internal CNC memory, that of the memory available for the user
and for the system.
In order to perform this test, the PLC program must be stopped. If it is running, the CNC will ask
the operator whether it is to be stopped or not.
Code test
This option checks the status of the internal CNC Flash memory. These memories contain the CNC
software version currently installed.
Hard disk test
Accessing this screen runs a test on the disk. Testing the hard disk includes a test of the surface.
This test is not carried out on a remote hard disk and the relevant message is displayed.
When detecting an error, it shows the relevant error message at the bottom of the window.
This mode shows the following information:
• Physical information.
Hard disk model installed and information on the physical and logic partition (cylinders, heads
and sectors). The physical and logic partitions might not be the same.
This information is only displayed for the local hard disk. When having a remote hard disk, this
information is not available.
• Logic information.
Size in bytes of each of the blocks the disk is divided into. Total number of blocks in the disk,
free and occupied. Number of sectors in a cluster.
The label is the name given to the disk when formatting it.
