·62·
Operating manual
CNC 8055
CNC 8055i
4.
EXECUTE / SIMULATE
·T· MODEL
SOFT: V02.2X
Block search. Switching from simulation to execution
4.1.4 Home searching restrictions
Block search is restricted in the following scenarios:
• In a program where a particular scaling factor is activated, the block search is automatically or
manually restricted to a block after that activation.
• In a program where axes are slaved with G77 or using PLC SYNCRO marks, the block search
is automatically or manually restricted to a later block.
The same restriction applies to a program having spindle synchronization.
• In a program that applies mirror image via PLC using MIRROR marks, the automatic or manual
search are restricted to later blocks.
• In a program containing a home search (G74), the automatic or the manual search is restricted
to later blocks.
4.1.5 Disabling the simulation and block search modes
The simulation and block search modes are available depending on the setting of g.m.p. DISSIMUL
(P184).
