·222·
Operating manual
CNC 8055
CNC 8055i
13.
DIAGNOSIS
·T· MODEL
SOFT: V02.2X
Configuration
13.1 Configuration
This option shows the current system configuration. Once this option has been chosen, two new
softkeys will appear in order to select the hardware configuration or the software configuration of
the system.
Hardware configuration
This option displays the following information:
Central Unit (CPU) configuration
It indicates the current configuration of the CNC’s central unit: Power supply, boards, video, CAN, etc.
CNC RESOURCES
It indicates, in Kb, the size of the user RAM memory, of the system and the memory space of the
hard disk (KeyCF).
PLC RESOURCES
It indicates whether the PLC is integrated into the CPU-CNC and the number of inputs and outputs,
local and remote.
LCD ADJUSTMENT (softkey available with monochrome LCD monitors)
Pressing this softkey shows new softkeys for adjusting the brightness/contrast over the adjustment
screen.
• The [+] and [-] softkeys may be used to adjust the brightness/contrast.
• Pressing the [RESTORE] softkey restores the previous values.
• Pressing the [SAVE] softkey assumes the new values.
Software configuration
This option shows:
• The available software options.
• The software version installed.
The version for the CNC and for the hard disk (KeyCF).
• The id codes of the unit. They are only to be used by the Service Department.
• The softkey to update the version.
When updating the software version with this softkey, it is not necessary to turn the CNC off and
back on or actuate the external switch to update the software version.
The "CODE VALIDATION" softkey must be used after consulting with the Service Department when
wishing to implement more software features.
