Operating manual
CNC 8055
CNC 8055i
GRAPHIC EDITOR
11.
·T· MODEL
SOFT: V02.2X
·199·
Utilities
11.1 Utilities
The various options available in this mode are:
"DIRECTORY" softkey
To display the directory of user screens and symbols that are stored in the hard disk (KeyCF) or
in an external device through the serial line.
Select the desired device and directory.
The CNC shows the size (in bytes) of each user screen (page) and symbol.
"COPY" softkey
To make copies within the hard disk (KeyCF) or between the hard disk (KeyCF) and an external
device.
Examples:
• To copy screen (page) 5 from the hard disk (KeyCF) to serial line.
• To copy screen (page) 50 from the serial line to the hard disk (KeyCF).
• To copy symbol 15 as symbol 16 within the hard disk (KeyCF).
"DELETE" softkey
To delete a screen or symbol from the hard disk (KeyCF); to do that, proceed as follows:
• Press the [DELETE] softkey
• Press the [PAGE] or [SYMBOL] softkey
• Key in the page or screen number to be deleted and press [ENTER]
The CNC will request confirmation of the command.
"RENAME" softkey
To assign a new name or comment to a page or symbol of the hard disk (KeyCF).
If there is another one with the same number, the CNC will display a warning message and it will
offer the chance to modify the command.
Examples:
• To change the page number from 20 to 55.
• To change the comment of symbol 10.
COPY PAGE 5 EN L SERIE (DNC)
COPY L SERIE (DNC) EN PAGE 50 ENTER
COPY SYMBOL 15 EN SYMBOL 16 ENTER
RENAME PAGE 20 A NEW NUMBER 55 ENTER
RENAME SYMBOL 10 A NEW NUMBER "Hello" ENTER
