Operating manual
CNC 8055
CNC 8055i
EXECUTE / SIMULATE
4.
·T· MODEL
SOFT: V02.2X
·57·
Block search. Switching from simulation to execution
4.1.1 Operating modes
Pressing <BLOCK SELECTION> displays a menu for selecting the starting block or the way to
operate.
First block
Pressing the <FIRST BLOCK> softkey gives access to the menu for selecting the block from which
to start executing the program.
FIRST LINE:
By pressing this key, the cursor will position at the first line of the program.
LAST LINE:
By pressing this key, the cursor will position at the last line of the program.
TEXT:
With this function it is possible to search for a text or character sequence starting at the current cursor
position.
When this softkey is pressed, the CNC requests the character sequence to be found. Once this text
has been keyed in, press the <END OF TEXT> softkey and the cursor will position over the first
occurrence of the keyed text.
The search will begin from the block the cursor is position on beginning at that block. The text found
will be highlighted being possible to continue with the search or to quit it.
Press [ENTER] to continue the search up to the end of the program. The CNC will begin the search
at the last text found and it will highlight it.
The search can be done as many times as desired. Once searched to the end of the program, it
will continue the search from the beginning.
Press the <ABORT> softkey or the [ESC] key to quit the search mode. When quitting the search
mode, the cursor will be positioned at the last matching text found.
LINE NUMBER:
After pressing this softkey, the CNC will request the number of the line to be found. Once that number
has been defined, pressing [ENTER] positions the cursor over the requested line.
