Operating manual
CNC 8055
CNC 8055i
MANUAL
6.
·T· MODEL
SOFT: V02.2X
·115·
Jog
6.1.2 Incremental jog
It allows to jog the selected axis in the selected direction an incremental step selected by the
Feedrate Override switch of the operator panel. This movement will be carried out at the jog feedrate
indicated by axis machine parameter "JOGFEED".
The available positions are 1, 10, 100, 1000 and 10000 that indicate the units to move the axis. These
units correspond to the units used for display.
Example: Display format: 5.3 in mm or 4.4 in inches.
The maximum permitted step is 10 mm or 1 inch regardless of the selected display format (for
example: 5.2 in mm or 4.3 in inches) the movement for the 1000 and 10000 positions will be the
maximum allowed.
After selecting the desired incremental move at the switch, if a jog key is pressed, the corresponding
axis will move the selected distance in the selected direction.
Switch position Distance
1 0.001 mm or 0.0001 inches
10 0.010 mm or 0.0010 inches
100 0.100 mm or 0.0100 inches
1000 1.000 mm or 0.1000 inches
10000 10.000 mm or 1.0000 inches
If while jogging an axis, the rapid key is pressed, the axis will move at the feedrate
established by machine parameter "G00FEED" for this axis as long as this key stays
pressed. This feedrate will be applied while this key is pressed and it will restore the
jogging feedrate percentage (0% to 120%) indicated in axis machine parameter
"JOGFEED" when this key is released.
