Operating manual
CNC 8055
CNC 8055i
DIAGNOSIS
13.
·T· MODEL
SOFT: V02.2X
·223·
Hardware test
13.2 Hardware test
This option checks the power supply voltages corresponding to the system and to the boards as
well as the internal temperature of the central unit. It displays the following information:
Supply voltage
It indicates the voltage of the lithium battery and the voltages supplied by the power supply. The
voltages supplied by the power supply are internally used by the CNC.
Next to the voltages, it displays the value range (maximum and minimum values), the real value and
whether it is OK or not.
Board voltage
It indicates which boards must be supplied with 24 Vdc and whether each one of them is properly
supplied.
Inside temperature
It shows the value range (maximum and minimum values), the inside temperature of the Central
Unit and whether that value is OK or not.
