·184·
Operating manual
CNC 8055
CNC 8055i
10.
PLC
·T· MODEL
SOFT: V02.2X
Restore program
10.7 Restore program
Select this option for the CNC to restore the PLC_PRG program from the hard disk (KeyCF).
The PLC program must not be running any PLC program, otherwise, the CNC will ask whether it
is desired to stop it or not.
After executing this instruction, the new source program recovered will replace the one that the PLC
previously had. This new one must be compiled and started in order for the PLC to execute it.
10.8 Resources in use
When selecting this option, the CNC will offer the softkeys to select the table of resources used in
the PLC program.
The following resource tables are available:
INPUTS (I)
OUTPUTS (O)
MARKS (M)
REGISTERS (R)
TIMERS (T)
COUNTERS (C)
