Operating manual
CNC 8055
CNC 8055i
3.
OPERATIONS VIA ETHERNET
·T· MODEL
SOFT: V02.2X
Access the CNC's hard disk from a PC
3.3 Access the CNC's hard disk from a PC
If the CNC is configured like another node in the network, it may be accessed from any PC of the
network knowing its IP. Only the CNC's hard disk may be accessed; i.e. it is not possible to access
programs in RAM nor read variables, tables, etc.
From the PC, it is possible to access the part-program directory of the hard disk and edit, modify,
etc. the programs stored. It is also possible to copy programs from the hard disk to the PC and vice
versa.
Protocol used
The FTP protocol is used to access the hard disk of the CNC. The FTP protocol permits transferring
files between a PC and a CNC connected to a local network or to internet. The FTP client, in charge
of managing the transfer, must be installed at the PC. The interface depends on the FTP client being
used.
When accessing the CNC from a PC via FTP, it shows the following directory structure.
Although the user may create new directories through the FTP, only the programs contained in the
"PRG" directory may be seen from the CNC.
If the CNC does not have a hard disk, it will show the directory empty and it will not allow sending
any program.
File transfer
To copy a file from the PC to the CNC.
• In any Windows
®
(95, 98, 2000 or XP) system. Drag the file from one folder to another or use
the keyboard shortcuts [CTRL]+[C] and [CTRL]+[V].
To copy a file from the CNC to the PC.
• In Windows
®
95 or 98. Click the right mouse button on the file, select the option to "Copy to folder"
and select the destination folder.
•In Windows
®
2000 or XP. Drag the file from one folder to another or use the keyboard shortcuts
[CTRL]+[C] (copy) and [CTRL]+[V] (paste).
The PC operative system may be Windows, Linux or Unix.
Windows® includes an FTP client in its Internet Explorer application from version 5.x on. From
Windows® 98 on, the Windows explorer has its own integrated FTP client.
BIN System folder used by the FTP protocol. It cannot be modified.
DISK CNC hard disk. The user can fully access it from the PC. Although subdirectories and files
may be defined, they won't be accessible from the CNC.
PRG Part-programs and PLC programs stored at the CNC. If this folder does not exist on start-up,
an empty one is created.
