Fagor CNC 8055 T User Manual

Operating manual
CNC 8055
CNC 8055i
PLC
10.
·T· MODEL
SOFT: V02.2X
·169·
Edit
END
This softkey positions the cursor over the last program block which is then selected quitting the "find"
option.
TEXT
With this function it is possible to search for a text or character sequence starting at the current cursor
position.
When this softkey is pressed, the CNC requests the character sequence to be found. Once this text
has been keyed in, press the "END OF TEXT" softkey and the cursor will position over the first
occurrence of the keyed text.
The search will begin from the block the cursor is position on beginning at that block. The text found
will be highlighted being possible to continue with the search or to quit it.
Press [ENTER] to continue the search up to the end of the program. The CNC will begin the search
at the last text found and it will highlight it.
The search can be done as many times as desired. Once searched to the end of the program, it
will continue the search from the beginning.
Press the "ABORT" softkey or the [ESC] key to quit the search mode. When quitting the search mode,
the cursor will be positioned at the last matching text found.
LINE NUMBER
After selecting this softkey, the CNC will request the number of the line to be found. After keying
in the desired number and pressing [ENTER], the cursor will position over that block which will then
be selected quitting the search mode.
"REPLACE" softkey
With this option it is possible to replace a character sequence with another throughout the selected
program. When selecting this option, the CNC requests the character sequence to be replaced.
Once the text to be replaced is indicated, press the "WITH" softkey and the CNC will request the
character sequence which will replace the previous one.
Once this text is keyed in, press the "END OF TEXT" softkey and the cursor will be positioned over
the first occurrence of the searched text.
The search will begin from the block the cursor is position on beginning at that block. The found text
will be highlighted and the following softkey options will appear:
REPLACE
It will replace the highlighted text and will continue the search for the indicated text. The new text
found will be highlighted and the softkeys will show the same "replacing" or "not replacing" options.
This search will be carried out from the text that was replaced up to the end of the program. If no
more occurrences of the text to be replaced are found, the CNC will quit this mode.
DO NOT REPLACE
It will NOT replace the highlighted text and will continue the search for the indicated text. The new
text found will be highlighted and the softkeys will show the same "replacing" or "not replacing"
options.
This search will be carried out from the text that was replaced up to the end of the program. If no
more occurrences of the text to be replaced are found, the CNC will quit this mode.
TO THE END
This option will find and replace the selected text throughout the whole program.
This "find and replace" will start at the highlighted text and will go on to the end of the program.
ABORT
This option will not replace the highlighted text and it will quit the "find and replace" mode.
