·122·
Operating manual
CNC 8055
CNC 8055i
6.
MANUAL
·T· MODEL
SOFT: V02.2X
Movement with an electronic handwheel
Configuring the additive handwheel
Handwheel resolution and maximum feedrate.
The resolution of the additive handwheel depends on the setting of parameter ADIMPG. There are
two options to set the resolution:
• The resolution of the handwheel is set by parameter ADIMPRES (P177) of the axis.
• The handwheel resolution is set with the switch of the operator panel. If the switch is not in the
handwheel position, it assumes a x1 factor.
Maximum feedrate allowed, due to the additive handwheel, is limited by parameter ADIFEED (P84).
Coordinates display
Parameter DIPLCOF determines whether the CNC takes into consideration or not the additive zero
offset when displaying the coordinates of the axes on the screen and when accessing the POS(X-
C) and TPOS(X-C) variables.
