·158·
Operating manual
CNC 8055
CNC 8055i
9.
STATUS
·T· MODEL
SOFT: V02.2X
CNC
9.1 CNC
This screen shows the number of the line that was being executed last time an execution error or
a power outage occurred. The CNC shows the program number and line number that was executing
as well as where the program is stored.
If that program called a subroutine and the CNC was executing it, it will show the subroutine number,
the program containing it and the line or block of the subroutine that it was executing.
Error LOG
The CNC's error register is accessed with the softkey "BB". This register saves an error history
indicating the error number and when it occurred.
The SAVE softkey may be used to save the register into a file. By pressing this softkey, the CNC
requests the number of the program to store that information.
The CNC was executing line 7 of program 12 stored in the hard disk.
That program called subroutine 33 and the CNC was executing line 15 of that subroutine.
The subroutine is defined in program 1000 that is stored in the CNC's RAM memory.
Unit
HARD DISK
MEMORY
Program
000012
001000
Line number
7
15
Subroutine
0033
