Operating manual
CNC 8055
CNC 8055i
PLC
10.
·T· MODEL
SOFT: V02.2X
·195·
Logic analyzer
Modify base
With this option it is possible to modify the "time base".
The status area is divided into several vertical stripes. Each stripe represents the amount of time
defined by the "time base" constant.
The "time base" is inversely proportional to the resolution of the signals; thus, the lower the "time
base" the greater the signal resolution and vice versa.
Pressing this softkey, the CNC will request the new value to be assigned to the time base. This value
is given in milliseconds.
