Operating manual
CNC 8055
CNC 8055i
GRAPHIC EDITOR
11.
·T· MODEL
SOFT: V02.2X
·209·
Texts
TEXT NUMBER
With this option it is possible to select a text used by the CNC itself in its various operating modes
and insert it into the current page or symbol.
To insert one of these predetermined texts, follow these steps:
1. Press the relevant softkey.
The CNC will display an area to define the text number; the cursor within this area can be moved
with the [] [] keys.
2. Indicate the desired number by keying it in from the keyboard and press [ENTER].
The CNC will show the text that has been selected. The CNC will display in its main window a
rectangle indicating the size of the text.
If another text is desired, key in the other number and press [ENTER] again.
Press [ESC] to cancel this option and the previous menu will be displayed.
3. Once the desired text has been selected, press [ENTER].
The typed text will remain in the editing window and the cursor will be positioned in the main
window.
4. Position the rectangle by moving the cursor.
5. Press [ENTER] to validate the command. The CNC will replace the rectangle with the indicated
text.
Note that once the text has been "entered", neither its size nor its color can be modified. Therefore,
these options must be selected before pressing [ENTER].
This application may be useful when the pages or symbols being edited are to be shown in other
languages since the CNC will translate them into the chosen language.
Usually, when the texts are to be shown in one single language, it is more practical to simply write them
up instead of searching them in a list of more than 1500 predetermined messages.
However, should anyone desire the printout of these predetermined texts, feel free to request it from
Fagor Automation.
