Operating manual
CNC 8055
CNC 8055i
GRAPHIC EDITOR
11.
·T· MODEL
SOFT: V02.2X
·211·
Modifications
MOVE SCREEN
With this option, it is possible to move a whole set of graphic elements and texts of the currently
selected screen. This option is not available when a symbol is selected.
When selecting this option, the CNC places the cursor in the middle of the screen and assumes
that point as the screen's reference point.
To move the screen, proceed as follows:
1. Move the cursor to the desired position for the page's reference point.
2. Press [ENTER] to validate the command. The CNC will move the whole set of graphic elements
and texts of the currently selected screen.
Press [ESC] to cancel this option and the previous menu will be displayed.
Repeat the previous operations to move the screen somewhere else. If not, press [ESC] and the
CNC will display the previous menu.
