Operating manual
CNC 8055
CNC 8055i
DIAGNOSIS
13.
·T· MODEL
SOFT: V02.2X
·227·
Adjustments
Once the graphic display area and the machine parameters have been defined, capture the data
by pressing the following softkeys:
SIMPLE It deletes the current graph and draws, over the theoretical circle, the machining
error enlarged according to the defined scale until a full circle is drawn or until the
STOP softkey or [ESC] key is pressed.
CONTINUOUSIt deletes the current graph and draws, over the theoretical circle, a series of
circles with the machining error enlarged according to the defined scale until the
STOP softkey or [ESC] key is pressed.
DELETE It may be pressed at any time, even while drawing the graph. It deletes the screen
and resets the statistics shown at its right.
During continuous graphics, it is possible to modify the machine parameters and view the new graph
over the previous one, or press the DELETE softkey to only display the new one.
The data shown by the CNC at the top right is updated while capturing data.
internal Maximum negative value of the error over the theoretical value, in microns or ten-
thousandths of an inch and its angular position.
external Maximum positive value of the error over the theoretical value, in microns or ten-
thousandths of an inch and its angular position.
Once data capture is done, it draws two lines indicating the angular positions of both errors on the
graph. They appear in dashed lines when the error exceeds the value assigned to the display area
in its quadrant and it goes on to the opposite quadrant.
While capturing points for the geometry test, the execution graphics stops drawing.
