Operating manual
CNC 8055
CNC 8055i
CNC - PC COMMUNICATION. TELEDIAGNOSIS
14.
·T· MODEL
SOFT: V02.2X
·249·
Advanced phone call
As advanced properties of the modem (the values are examples).
If it offers the option to display the window for the dialing terminal, select the options so it is not
shown in any case.
3. The next step refers to the virtual connections. Choose the option "Do not allow private virtual
connections".
4. To make the connection, define the users allowed to connect with the PC. The window shows
a list of users. To define a new user, press the –Add– button.
To add a new user, define the name, the password and password confirmation. The "Full name"
field is optional.
5. The last step consists in configuring the network components. In this case, we'll use the Internet
protocol TCP/IP.
Select the TCP/IP protocol from the list of components and press the properties button.
Indicate the TCP/IP addresses. Enter in the "From" field an address that belongs to the local
network where the PC is and in the "For" field the next one.
For safety, deselect the option that lets the caller access the local network.
6. Define the name by which the new connection must be recognized. This is the name that will
appear on the PC's net directory. Just select it from the list to start the connection.
Data bits 8
Parity None
Stop bits 1
Modulation Standard
For example, if the network the PC is in uses 10.0.xx.xx type addresses, the "From" field may use the
address 10.0.68.70 and the "For" the next one, i.e. 10.0.68.71, if they are not being used.
