·80·
Operating manual
CNC 8055
CNC 8055i
4.
EXECUTE / SIMULATE
·T· MODEL
SOFT: V02.2X
Graphics
COLORS OF SOLID
With this option it is possible to modify the colors used to draw the solid. They can only be used
in SOLID graphics. There are the following parameters:
• Color for the cutter.
• Color for the part.
• Color for the axes.
• Color for the clamps.
• The color to draw the internal Y side, machined side.
• The color to draw the internal Z side, machine side.
In order to re-define the display area, the CNC will show, to the right of the screen, several windows
indicating the currently selected colors.
Among the various colors offered, it is also possible to select "black". If this color is selected to draw
the part, none of the machining operations will be shown.
Use the [] [] keys to select the window and once selected, modify it using the [] [] keys.
Once the desired colors have been selected, press [ENTER] to validate the new choices or ESC
to ignore the changes and leave this function with the original values intact. Press [ESC] to quit this
function without making any changes to this field.
