LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 8-24 Section 8-2 - DISASSEMBLY/RE-ASSEMBLY
8-2-4-4 Assembly procedure (cont’d)
10.)Screw 2 screws (2159626, PH M4X20) to assemble the Arm stopper.
11.)Screw 2 screws (2159625, PH M4X8 W/SP) to assemble the Lower arm guide bracket.
12.)Tie the Cables with Cable tie.
Figure 8-45 Installing the Arm stopper
Figure 8-46 Assembling the Lower arm guide bracket
Figure 8-47 Tying the cables
