GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Chapter 8 - Page 8-31

8-2-4-4 Assembly procedure (cont’d)

24.)Screw 2 screws (2337572, FH M3X6 WHT) to assemble the Arm cover L & R.

25.)Screw 4 screws (2159634, BH M4X10 WHT) to assemble the Arm bottom Cover.

Figure 8-59 Assembling the Arm Cover L & R

Figure 8-60 Assembling the Arm bottom cover
