KAYENNE — User Manual 125
Button Mapping
To Learn a Default Keyframe:
1. Setup the entire Kayenne Control Panel to the desired state.
2. Press the Learn button in the Default Keyframe pane.
Pressing the Set button overwrites the Default Keyframe with factory
defaults.
Note Save your current Suite Prefs, which includes the Default Keyframe settings
before resetting to factory defaults.
Button Mapping
Button mapping assigns video sources to source selection buttons (Source
Button mapping). Button mapping is also used to assign Aux buses to del
-
egation buttons (Aux Delegate mapping). This allows you to customize the
Control Panel and configured Remote Aux Panels to meet your individual
needs. Button mapping settings are included as part of Panel Preferences,
and can be saved and instantly loaded for use at any time (see
File Opera-
tions on page 149).
Button mappings of the Control Panel are set at the factory before shipment
to the settings listed in
Table 3 and Table 4 for 4-ME systems and Table 5
and Table 6 for 2-ME systems).
There are four source button delegation levels with Kayenne. Table 3 shows
the source to button mapping for the 1st (unshifted) and second levels for
a 35 button 4-ME system.
Table 4 shows the 3rd and 4th shifted levels.
Table 3. 4-ME Factory Configured Source to Button Mapping 1st and 2nd Levels
Panel Button
1st
(unshifted)
2nd
Button 1 Black Test
Buttons 2-27 Source 2 - 27 Source 37 - 64
Button 28, 29 Bkgd 2, Bdgd1 Bkgd 2, Bdgd1
Button 30-32 ME 1A - ME 3A ME 1A - ME 3A
Button 33,34 Shift, Shift Shift, Shift
Button 35 Delegate Delegate
Table 4. 4-ME/35 Factory Configured Source to Button Mapping 3rd and 4th Levels
Panel Button (35) 3rd 4th
Buttons 1-27 Source 71 - 99 Source 106 - 134
Button 28, 29 Bkgd 2, Bdgd1 Bkgd 2, Bdgd1
Button 30-32 ME 1A - ME 3A ME 1A - ME 3A
