20 KAYENNE — User Manual
Section 1 — Introduction
MEs available, as well as the number of video inputs, outputs, GPIOs and
Relay Tallies.
Figure 1. Kayenne Video Processor Frames
Kayenne Control Surfaces
A Kayenne control surface typically consists of a Control Panel, a Menu
Panel with an included articulated support arm, a Panel Control Unit
(PCU) frame, and optional Satellite Panels. This control surface has an
innovative modular design. Representative Kayenne control surfaces are
shown in the following illustrations.
Figure 2. Kayenne 4-ME 35 Control Surface
Figure 3. Kayenne 3-ME 35 Control Surface
8623266_06
Kayenne 8-RU
Video Processor Frame
Kayenne 4-RU
Video Processor Frame
4-ME 35 Control Panel Menu Panel
Menu Panel
Articulated
Arm
8623266_01
Panel Control Unit (PCU)
Optional Device
Control Module
Optional
Module
Menu Panel
Menu Panel
Articulated
Arm
8623266_02
Panel Control Unit (PCU)
3-ME 35 Control Panel
Optional Device
Control Module
