GRASS VALLEY KAYENNE - V2.0 User Manual

KAYENNE — User Manual 259
eDPM Operations
be selected (including multi-select) and the soft knobs and joystick are del-
egated to controlling eDPM parameters (Figure 174).
Note All keyer buttons will be disabled in the eDPM mode.
Figure 174. Multi-Function Module, eDPM Control Mode
You can scroll through video, key, or video/key sources within an eDPM
from the MFM, in eDPM, E-MEM Mode using the
SelV and SelK soft but-
tons:
SelV — When toggled on (white) allows you to scroll through Video-only
sources for the selected eDPM using the soft knobs (Channels 1-4).
SelK — When toggled on (white) allows you to scroll through Key-only
sources for the selected eDPM using the soft knobs (Channels 1-4).
SelV and SelK — When both are toggled on (white) allows you to scroll
through Video/Key sources for the selected eDPM using the soft knobs
(Channels 1-4).
eDPM Mode Menus
Touching the eDPM Mode button (bottom left) changes the menu to the
eDPM Mode (
Figure 175).
W
ipe
ipe
1
Key
Key
5
Key
Key
3
Key
Key
1
W
ipe
ipe
2
Key
Key
6
Key
Key
4
Key
Key
2
CH 1
CH 2
CH 3
CH 4
8623267_25
SzLc
3dLc
ROT
SPIN
Axis
Adel
Last
ASPT
SKEW PRSP 2DLc PGLB
CROP SHAD FILM FRZ
SGLB
DELG
DELG DELG
SLcX
SLcY
Size
PGMK2-iDPM
SRC TARG
XFER
SLcX SLcY
Size
HOME
EMEM
SelV SelK
