MFG-2000 Series User Manual
250
HTTP Port 80 (fixed)
Panel Operation
1. Connect the LAN cable to the
rear panel LAN port.
LAN
2. Press the Utility key followed
by Interface (F2) and LAN
(F3).

a

DHCP
Connections
Use DHCP to automatically configure the IP
address of the unit for networks with a DHCP
server.
3. Press Config (F2) followed by
DHCP (F1), Done(F5). Press
Done(F5) again.
g
D
D
D
Auto IP
Connections
Use Auto IP to automatically configure the IP
address of the unit when it is directly connected
to a host PC via the Ethernet cable.
4. Press Config (F2) followed by
Auto IP (F2), Done(F5). Press
Done(F5) again.
g

D
D
Manual IP
Connections
Manually configure the IP address.
5. Press Config (F2) followed by
Manual (F3).
g
aa
6. Press IP Addr (F1) and set the
IP address using the number
pad. Press Done (F1) to
complete setting the IP
Address.
dd
D
