GW Instek MFG-2000 Series User Manual

APPENDIX
391
Frequency
DC to 20kHz
Ground Isolation
42Vpk max
Trigger Output
Type
For ARB,Burst,Sweep
Level
TTL Compatible into 50Ω
Pulse Width
>16ns
Maximum Rate
25MHz
Fan-out
≥4 TTL Load
Impedance
50Ω Typical
Frequency
Counter
Range
5Hz to 150MHz
Accuracy
Time Base accuracy±1count
Time Base
±20ppm (23˚C ±5˚C)
Resolution
The maximum resolution is:
100nHz for 1Hz, 0.1Hz for
100MHz.
Input Impedance
1kΩ/1pf
Sensitivity
35mVrms ~ 30Vrms (5Hz to
150MHz)
Ground Isolation
42Vpk max
Dual Channel
Function
(CH1/CH2)
Phase
-180° ~180°
Synchronize phase
Track
CH2=CH1
Coupling
Frequency(Ratio or Difference)
Amplitude & DC Offset
Dsolink
√
Save/Recall
10 Groups of Setting Memories
Interface
LAN, USB
Display
4.3’’ TFT LCD
480 × 3 (RGB) × 272
General
Specifications
Power Source
AC100~240V, 50~60Hz or
AC100~120V, AC220~240V,
