GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
392
50~60Hz
Power Consumption
30W or 80W
(With power amplifier)
Operating Environment
Temperature to satisfy the
specification : 18 ~ 28˚C
Operating temperature :
0 ~ 40˚C
Relative Humidity:
≤ 80%, 0 ~ 40˚C
≤70%, 35 ~ 40˚C
Installation category： CAT II
Operating Altitude
2000 Meters
Pollution Degree
IEC 61010 degree 2, Indoor use
Storage Temperature
-10~70˚C, Humidity: ≤70%
Dimensions (WxHxD)
266(W) x 107(H) x 293(D) mm
Weight
Approx. 2.5kg
Approx. 4kg(With power
amplifier)
Safety designed to
EN61010-1
Accessories
GTL-101× 1(MFG-21XX)
GTL-101× 2(MFG-22XX)
Quick Start Guide ×1
CD (user manual + software) ×1
Power cord×1
(1). A total of ten waveforms can be stored. (Every waveform can be composed of a
maximum of 16k points.)
(2). Add 1/10th of output amplitude and offset specification per ºC for operation outside of
0ºC to 28ºC range (1-year specification).
(3). DC offset set to zero,
(4). Jitter specification for RF Generator: 20ppm+5ns.
(5).Only Pluse channel support
(6). Only one channel output
