8 Intelligent panels
8.6 ASV target graphics window
The ASV target graphics window (Figure C-4) shows how the
adaptive lung controller moves toward its targets. And it shows
both the target and actual parameters for tidal volume, fre-
quency, pressure, and minute ventilation.
See Appendix C, ASV, for detailed information on ASV, includ-
ing how to interpret the data in the target graphics window.
8.7 INTELLiVENT
®
-specific intelligent panels
For detailed information, see the INTELLiVENT
®
-ASV manual.
8.8 Quick Wean-specific intelligent panels
For detailed information, see the INTELLiVENT
®
-ASV manual.
