Figure 2-10. CO
2
, SpO
2
, Aeroneb modules
1 CO
2
or SpO
2
connector
2 Aeroneb connector (Aeroneb/HAMILTON-H900 humidifier
module not shown)
2.6 Verifying the oxygen cell installation
This device uses an integrated oxygen cell to monitor the deliv-
ered oxygen concentration. Before operating the ventilator,
verify the cell is present and properly connected (Figure 2-11).
If a cell is not present, install one according to the instructions
found in section 11.3.3.
