1-24 624074/07
1 General information
4 Cuff pressure controller with luer connection
1
5 Expiratory valve cover and membrane
6 From patient port. The expiratory limb of the patient
breathing circuit and the expiratory valve are connected
here.
7 Exhaust port. Expiratory valve cover opening to
ambient air.
8 Ventilation unit LED panel. Redundant display of
ventilator status. It is intended to provide status infor-
mation when the Ventilation Cockpit is disconnected,
as follows:
An emergency situation exists (red LED)
The ventilator is connected to AC mains power
(blue LED)
Power switch is on (green LED)
9 Sensor or Aeroneb option module with connector
10 Inspiratory filter
11 To patient port (inspiratory outlet). The inspiratory
filter and the inspiratory limb of the patient breathing
circuit are connected here.
1. Not available in all markets.
