Measuring
Adapting to the transducer
166 A0534-30.0 HBM: public MGCplus
9. In the Decimal places edit field enter the desired number of decimal
places and confirm with
.
10. In the Step selection field select the desired step and confirm with
.
Information
The step refers to the last decimal place of the display value.
Example:
Entry 10.0C
Step 1 means display jumps every 0.1C
Step 5 means display jumps every 0.5C
Entry 50.000 C
Step 1 means display jumps every 0.001C
Step 5 means display jumps every 0.005C
11. Use the Switch key
to go to measuring mode and confirm the con
firmation prompt with
.
7.3.8 Current and voltage measurement
To measure current and voltage signals you will need amplifier module
ML01B or ML801B and AP402i. For simple voltage measurements you can
also use the ML801B multi-channel module with connection board AP801 or
AP801S6.
The settings are explained with the following example:
A torque transducer with integrated amplifier returns a maximum output
signal of 3V, corresponding to a nominal (rated) torque of 20 Nm. The
display range will be set to 20.000 Nm. An output signal of 10V is required
for control.
