9.1.5 Recording status
Bar display
This realization shows the current status of the recording.
Recording comments
User-specific comment (for example the test series number).
Sampling rate
The current sampling rate for all defined channels is shown here.
Measurement time
Time elapsed since the beginning of the measurement period.
Periods
Number of measurement periods
File name
Name of the saved recording file. The file will not be overwritten when the
measurement program is restarted. Instead the counter (last four places)
will be incremented.
xxx MB free
Indicates the free storage space on the hard disk.
Information
The MGCplus computer detects when the storage capacity of the hard disk
falls below 1 MB. In this case recording is canceled and the measurement
file is closed.
Test series 3 SAMPLING RATE: 50Hz
TIME: 00: 00: 00 PERIODS: 100
FILE NAME: MGCP0000.MEA 120 MB FREE
Load AP1 Acal
−4.0S 16.0S
1
Pre-trigger
Post-trigger
Current measurement period
Recording comments
Bar display
To Next Page
