Torque flange T10 series, T40 series
MGCplus A0534-30.0 HBM: public 53
4.3.10 Torque flange T10 series, T40 series
1)
4.3.10.1 Torque measurement
Supply voltage (18V ... 30 V)
Torque measurement signal, frequency output (+)
Calibration signal trigger (approx. 5V)
Ground
Plug 1
Md
Cable shield
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye= yellow; gn= green; gy= gray
5
6
12
13
8
AP17
1
8
9
15
Power supply (0V)
Torque measurement signal, frequency output (-)
14
Hsg.
23
7/5 6
4
1
bk
bu
w
h
r
d
gn
g
y
ye
1)
Does not apply to version KF1.
