HBM MGCplus - Rotational Speed Measurement with Inductive Transducers

Connection
Torque shaft (T4A, T5, TB1A)
MGCplus A0534-30.0 HBM: public 61
4.3.11.2 Rotational speed measurement with inductive transducers
2
Rotational speed
measurement signal
(+)
AP460i
1
1
2
3
4
5
67
8
910
1 k 5 k
5 V
U
max
= 30V
Rotational speed
measurement signal
(-)
Inductive
tachometer
(T-R coil)
Please note the setting information for T-R coils on page 152.
