7.4.1 Direct entry of transducer characteristics
1. Use
or a direct entry to choose the desired channel (for example 3.2
).
2. Use
to switch to Setup mode.
3. Press the
function key.
4. In the pull-up menu select Transducer and confirm with
.
5. Use
to select transducer type Deltatron 1V and confirm with .
6. Use
to switch to the Unit selection field and press . Select m/s
2
as the unit and confirm with .
7. In both the Zero point edit fields enter the value 0.
8. In the left edit field Nominal (rated) value enter the value 300.
9. In the right edit field Nominal (rated) value enter the value 0.3.
10. Use to select the
Adjust amplifier
button and confirm with . If
you do not want to make any more changes to the display or output
characteristics, you can now continue with step 15.
11. Go back to the pull-up menu with
.
AmplifierSystem Display Options
Transducer
Signal conditioning
Display
Analog outputs
Switch
0.30000 ...
Type Deltatron 1V
Current feed: 2−20mA
Unit:
V
i
Zero pt.:
Nom. val.:
TRANSDUCER CHANNEL1
m/s
2

0.00000 ... 0.00000 ...
300.0000 ...
calibrate...calibrate... Adjust amplifier
measure
