HBM MGCplus - LVDT Transducers

Connection
LVDT transducers
MGCplus A0534-30.0 HBM: public 45
4.3.5 LVDT transducers
Measurement signal (+)
Bridge excitation voltage (+)
Sense lead (-)
Sense lead (+)
Bridge excitation voltage (-)
Cable shield
)
8
5
6
13
12
Hsg.
AP455i
Measurement signal (-)
15
LVDT transducers
1
2
3
5
6
Hsg.
AP455iS6
4
6
4
3
1
5
2
