4.5.4 Inputs and outputs of AP75
The AP75 connection board has 8 digital inputs, 8 digital outputs and 2 ana
log outputs. The digital outputs must be operated with an external current
feed (12 V...24 V). The AP75 connection board can be operated together
with the special function modules ML78B or ML70B.
24V
U
D01
Wiring example for
using an analog
output.
