4.3.8 Single strain gage
4.3.8.1 Single strain gage on AP14
8
5
15
12
AP14
1
8
9
15
Hsg.
Excitation voltage (+)
Sense lead (-)
Measurement signal (+),
sense lead (+)
Excitation voltage (-)
SG
Three-wire connection Four-wire connection
SG
