Connection
Resistors, Pt100
72 A0534-30.0 HBM: public MGCplus
4.3.15 Resistors, Pt100
Excitation voltage (-)
Cable shield
R
Excitation voltage (+)
Measurement signal (-)
Measurement signal (+)
1
4
Hsg.
AP835
3
2
1
2
4
3

