7.3.5 Adjusting the rotational speed channel, frequency
measurement
The following calculation is required to adjust the torque channel:
Nominal (rated) rotational speed: n
A
= 3000 rpm
Number of pulses/revolution: i = 360 (see table below, type T10F)
n
A
xi
60
+ Pulse frequency
In this example:
3000 x 360
60
=
18,000 Hz
i.e. a frequency up to 18,000 Hz must be measured.
Torque measurement
shaft
Number of pulses per revolution
(two outputs offset by 90°)
T4WA 90
T30FNA 30
T32FNA 15
T34FNA 15
T10F/T10FS 15...720/15...360
1)
T10FM 15...720
1)
See T10F/T10FS documentation.
